Engine

Engine Model 3C100LWH-U3
Engine Gross Power 21 hp (15.6 kW)
Rated Speed 3,200 rpm
No. of Cylinders 3
Fuel Type Diesel
Displacement 61.5 cu. in (1,007 cc)
Fuel Tank Capacity 6.7 gal. (25.5 L)

Transmission

Transmission Type Hydrostatic
Main Gear Hydrostatic
No. of Travel Speeds – Forward / Reverse Infinite, 2 Range
Min. Travel Speed of Forward w/ Ag @ Engine rated speed 0 mph (0 km/h)
Max. Travel Speed of Forward w/ Ag @ Engine rated speed 9.57 mph (15.4 km/h)

Power Take-Off

PTO Type Trans Independent
PTO Power 16.3 hp (12.2 kW)
Rear PTO Speeds(1st) 540 rpm
Mid PTO Speeds 2,200 rpm

Brakes and Clutch

Brakes Wet Multi Disc

Dimensions w/ AG Tire

Length w/ 3-point hitch 99.3 in. (2,523 mm)
Width 45.9 in. (1,168 mm)
From Top of the Highest Point 88 in. (2,226 mm)
Wheelbase 55.1 in. (1,400 mm)
Ground Clearance 6.4 in. (162 mm)
Front Tread Ag Tires – Min 44.6 in. (1,133 mm)
Rear Tread Ag Tires – Min 46 in. (1,168 mm)

Hydraulics

Total Pump Flow 6.97 gpm (26.4 L/min)

3-Point Hitch

Standard Category Category 1
Maximum Lifting Capacity (24”aft. of hitch) 700 lbs. (318 kg)
Control Type Position

Weight

Weight w/ Ag Tires w/ ROPS 1,554 lbs. (705 kg)
AvailabilityBrochure
Engine Model3C100LWH-U3
Engine Displacement007 cc), 61.5 cu. in (1
Engine Horsepower21 hp (15.6 kW)
Fuel Tank Capacity6.7 gal. (25.5 L)
Fuel TypeDiesel
