K9 2400 CAB UTILITY VEHICLE

Engine

Engine Model 3C100LFU-U2
Engine Type 4-Cycle Diesel, 3 Cyl., Inline Vertical, Water-Cooled
Engine Gross 24 hp (17.89 kW)
Displacement 61.45 cu. in. (1,007 cc)
Rated Revolution 3,000 rpm
Fuel Tank Capacity 9.7 gal. (37 ℓ)

Drive Train

Type Belt CVT
Gear Range Low, High, Neutral, Reverse
Ground Speed 0-31 mph (0-50 km/h)
Brake Front/Rear Hydraulic Disc

Suspension

Front Suspension Independent, Double A-Arm (Wishbone Type)
Rear Suspension Independent, Double A-Arm (Wishbone Type)

Steering

Type Hydraulic Power

Dimensions

Length 119.8 in. (3,045 mm)
Width 62.5 in. (1,590 mm)
Height 76.7 in. (1,950 mm)
Max Front Wheel Tread 49.7 in. (1,262 mm)
Max Rear Wheel Tread 49.8 in. (1,264 mm)
Wheelbase 85.8 in. (2,180 mm)
Weight 2,050 lbs. (930 kg)
Ground Clearance 12.5 in. (318 mm)
Towing Capacity 1,300 lbs. (590 kg)
Payload Capacity 1,598 lbs. (725 kg)
Turning Radius 14.1 ft. (4.3 m)

Cargo Bed

Length x Width x Depth 43.7 x 58.2 x 11.5 in. (1,110 x 1,480 x 293 mm)
Bed Capacity 1,102 lbs. (500 kg)
Engine Displacement007 cc), 61.45 cu. in. (1
AvailabiltyBrochure
Engine Model3C100LFU-U2
Fuel Tank Capacity9.7 gal. (37 ℓ)
Engine Horsepower24.5 hp (18.3 kW)
