Engine
Engine Model | 3F183T |
Engine Gross Power | 60 hp (44.7 kW) |
Rated Speed | 2,600 rpm |
No. of Cylinders | 3 |
Fuel Type | Diesel |
Aspiration | Turbo Charged |
Displacement | 111.4 cu. in. (1,826 cc) |
Fuel Tank Capacity | 14.8 U.S. gal. (56 L) |
Transmission
Transmission Type | Hydrostatic |
Shuttle | None |
No. of Travel Speeds – Forward / Reverse | 3 Range |
Min. Travel Speed of Forward w/ Ag @ Engine rated speed | 0 mph (0 km/h) |
Max. Travel Speed of Forward w/ Ag @ Engine rated speed | 18.26 mph (29.38 km/h) |
Power Take-Off (PTO)
PTO Type Trans | Independent |
PTO Power | 48.3 hp (36 kW) |
Rear PTO Speeds (1st) | 540 rpm |
Mid PTO Speed | 2,000 rpm (Optional) |
Brakes and Clutch
Brakes | Wet Multi Disc |
Clutch | None |
Dimensions w/ AG Tire
Length w/ 3-point hitch | 139.6 in. (3,547 mm) |
Width | 65.7 in. (1,669 mm) |
Height from Top of ROPS | 103.1 in. (2,618 mm) |
Wheelbase | 75.6 in. (1,920 mm) |
Ground Clearance | 15.7 in. (400 mm) |
Front Tread Ag Tires – Min | 53.3 in. (1,355 mm) |
Rear Tread Ag Tires – Min | 52.5 in. (1,324 mm) |
Turning Radius w/ Brake | 9.97 ft. (3.04 m) |
Hydraulics
Pump | Gear |
Pump Capacity (Max. Flow Rate) | 17.9 GPM (67.6 L/min) |
3-Point Hitch
Standard Category | Category I & II |
Lift Capacity, 24′ aft of hitch | 3,177 lbs. (1,441 kg) |
Control Type | Position with Draft Control |
Weight
Weight with Ag Tires | 4,198 lbs. (1,904.2 kg) |
