| Model | ZXC48 SE | ZXC54 SE | ZXC60 SE |
Engine |
|||
| Type | Kohler Command PRO® | Kohler Command PRO® | Kohler Command PRO® |
| Engine Gross hp (kW) | 22.5 (16.77) | 23.5 (17.52) | 25 (18.64) |
| Displacement cu. in. (cc) | 42.35 (694) | 42.35 (694) | 45.58 (747) |
| Choke | Manual | Manual | Manual |
| Fuel Tank Capacity gal. (l ) | 12.5 (47.31) | 12.5 (47.31) | 12.5 (47.31) |
| Fuel Requirement | Unleaded Gasoline (87 Octane or higher) | Unleaded Gasoline (87 Octane or higher) | Unleaded Gasoline (87 Octane or higher) |
Drive Train |
|||
| Model | Hydro-Gear ZT-3400 | Hydro-Gear ZT-3400 | Hydro-Gear ZT-3400 |
| Displacement (Pump/Motor) cc | 12/16 | 12/16 | 12/16 |
PTO Type |
|||
| Clutch ft./lb. | 200 | 200 | 200 |
Electrical |
|||
| Charging System amp | 15 | 15 | 15 |
Tire Size |
|||
| Front | 13×6.5-6 | 13×6.5-6 | 13×6.5-6 |
| Rear | 23×10.5-12 | 23×10.5-12 | 23×10.5-12 |
Traveling Speeds |
|||
| Forward mph (km/h) | 10 (16.1) | 10 (16.1) | 10 (16.1) |
| Parking Brake | Internal Integrated in Axle | Internal Integrated in Axle | Internal Integrated in Axle |
Dimensions |
|||
| Overall Length in. (mm) | 80.7 (2,049.78) | 80.7 (2,049.78) | 81.7 (2,075.18) |
| Overall Width in. (mm) | 60.7 (1,541.78) | 67.3 (1,709.42) | 72.6 (1,844.04) |
| Overall Height in. (mm) | 71.5 (1,816.1) | 71.5 (1,816.1) | 71.5 (1,816.1) |
| Wheelbase in. (mm) | 48.5 (1,231.9) | 48.5 (1,231.9) | 49.5 (1,257.3) |
| Width (Tire to Tire) in. (mm) | 51.3 (1,303.02) | 51.3 (1,303.02) | 51.3 (1,303.02) |
| Approximate Curb Weight lb. (kg) | 939 (425.92) | 957 (434.08) | 992 (449.96) |
Mower Deck |
|||
| Mower Deck Type | Fabricated | Fabricated | Fabricated |
| Lift Mechanism | Foot Pedal | Foot Pedal | Foot Pedal |
| Deck Steel Thickness | 10-gauge with 7-gauge at edge area | 10-gauge with 7-gauge at edge area | 10-gauge with 7-gauge at edge area |
| Anti-Scalp Ball Rollers | 5 (4 front, 1 rear) | 6 (4 front, 2 rear) | 8 (4 front, 4 rear) |
| Cutting Width of Mower in. (mm) | 48 (1,219.2) | 54 (1,371.6) | 60 (1,524) |
| Blades | Notched (Opt. Serrated) | Notched (Opt. Serrated) | Notched (Opt. Serrated) |
| Cutting Height in. (mm) | 1.5-5 (38.1-127) | 1.5-5 (38.1-127) | 1.5-5 (38.1-127) |
| Discharge Chute | Side (Molded Rubber) | Side (Molded Rubber) | Side (Molded Rubber) |
| Deck Height Adjustment | Dial Type | Dial Type | Dial Type |
Seat |
|||
| Suspension | Standard (3 Inch Suspension with High Back) | Standard (3 Inch Suspension with High Back) | Standard (3 Inch Suspension with High Back) |
| Sliding Adjustment | Standard | Standard | Standard |
| Arm Rest | Standard | Standard | Standard |
| Seat Belt | Standard | Standard | Standard |
Standard/Optional |
|||
| Foldable ROPS | Standard | Standard | Standard |
| Head Light | Standard | Standard | Standard |
| Power Socket | Standard | Standard | Standard |
