| Model | ZXR48 | ZXR54 | ZXR60 |
Engine |
|||
| Type | Briggs & Stratton Professional Series™ | Briggs & Stratton Professional Series™ | Briggs & Stratton Professional Series™ |
| Engine Gross hp (kW) | 22 (16.40) | 24 (17.89) | 27 (20.13) |
| Displacement cu. in. (cc) | 44.18 (724) | 44.18 (724) | 49.42 (810) |
| Choke | Auto | Auto | Auto |
| Fuel Tank Capacity gal. (l ) | 7.5 (28.39) | 7.5 (28.39) | 7.5 (28.39) |
| Fuel Requirement | Unleaded Gasoline (87 Octane or higher) | Unleaded Gasoline (87 Octane or higher) | Unleaded Gasoline (87 Octane or higher) |
Drive Train |
|||
| Model | Hydro-Gear ZT-2800 | Hydro-Gear ZT-2800 | Hydro-Gear ZT-3200 |
| Displacement (Pump/Motor) cc | 10/16 | 10/16 | 10/16 |
PTO Type |
|||
| Clutch ft./lb. | 125 | 125 | 125 |
Electrical |
|||
| Charging System amp | 16 | 16 | 16 |
Tire Size |
|||
| Front | 13×5-6 | 13×5-6 | 13×6.5-6 |
| Rear | 22×9.5-10 | 22×9.5-10 | 23×9.5-12 |
Traveling Speeds |
|||
| Forward mph (km/h) | 8 (12.87) | 8 (12.87) | 9 (14.48) |
| Parking Brake | Internal Integrated in Axle | Internal Integrated in Axle | Internal Integrated in Axle |
Dimensions |
|||
| Overall Length in. (mm) | 80.7 (2,049.78) | 80.7 (2,049.78) | 81.7 (2,075.18) |
| Overall Width in. (mm) | 60.7 (1,541.78) | 67.3 (1,709.42) | 72.6 (1,844.04) |
| Overall Height in. (mm) | 70.5 (1,790.7) | 70.5 (1,790.7) | 71.5 (1,816.1) |
| Wheelbase in. (mm) | 48.5 (1,231.9) | 48.5 (1,231.9) | 49.5 (1,257.3) |
| Width (Tire to Tire) in. (mm) | 50.3 (1,277.62) | 50.3 (1,277.62) | 50.3 (1,277.62) |
| Approximate Curb Weight lb. (kg) | 893 (405.05) | 910 (412.76) | 948 (430.00) |
Mower Deck |
|||
| Mower Deck Type | Fabricated | Fabricated | Fabricated |
| Lift Mechanism | Foot Pedal | Foot Pedal | Foot Pedal |
| Deck Steel Thickness | 10-gauge with 7-gauge at edge area | 10-gauge with 7-gauge at edge area | 10-gauge with 7-gauge at edge area |
| Anti-Scalp Ball Rollers | 5 (4 front, 1 rear) | 6 (4 front, 2 rear) | 8 (4 front, 4 rear) |
| Cutting Width of Mower in. (mm) | 48 (1,219.2) | 54 (1,371.6) | 60 (1,524) |
| Blades | Notched (Opt. Serrated) | Notched (Opt. Serrated) | Notched (Opt. Serrated) |
| Cutting Height in. (mm) | 1.5-5 (38.1-127) | 1.5-5 (38.1-127) | 1.5-5 (38.1-127) |
| Discharge Chute | Side (Molded Rubber) | Side (Molded Rubber) | Side (Molded Rubber) |
| Deck Height Adjustment | Dial Type | Dial Type | Dial Type |
Seat |
|||
| Suspension | Optional | Optional | Optional |
| Sliding Adjustment | Standard | Standard | Standard |
| Arm Rest | Standard | Standard | Standard |
| Seat Belt | Standard | Standard | Standard |
Standard/Optional |
|||
| Foldable ROPS | Standard | Standard | Standard |
| Head Light | Optional | Optional | Optional |
| Power Socket | Standard | Standard | Standard |
AvailabilityBrochure
