Engine
| Engine Model | 3C100LFH-U2 |
| Engine Gross Power | 24.5 hp (18.3 kW) |
| Rated Speed | 3,200 rpm |
| No. of Cylinders | 3 |
| Fuel Type | Diesel |
| Displacement | 61.5 cu in. (1,007 cc) |
| Fuel Tank Capacity | 6.7 gal. (25.5 L) |
Transmission
| Transmission Type | Hydrostatic |
| Main Gear | Hydrostatic |
| No. of Travel Speeds – Forward / Reverse | Infinite, 2 Range |
| Min. Travel Speed of Forward w/ Ag @ Engine rated speed | 0 mph (0 km/h) |
| Max. Travel Speed of Forward w/ Ag @ Engine rated speed | 9.57 mph (15.4 km/h) |
Power Take-Off
| PTO Type | Independent |
| PTO Power | 18.5 hp (13.9 kW) |
| Rear PTO Speeds(1st) | 540 rpm |
| Mid PTO Speeds | 2,200 rpm |
Brakes and Clutch
| Brakes | Wet Multi Disc |
Dimensions w/ AG Tire
| Length w/ 3-point hitch | 99.3 in. (2,523 mm) |
| Width | 45.9 in. (1,168 mm) |
| Height From Top of the Highest Point | 88 in. (2,226 mm) |
| Wheelbase | 55.1 in. (1,400 mm) |
| Ground Clearance | 6.4 in. (162 mm) |
| Front Tread Ag Tires – Min | 44.6 in. (1,133 mm) |
| Rear Tread Ag Tires – Min | 46 in. (1,168 mm) |
| Turning Radius w/ Brake | 8.2 ft. (2.54 m) |
Hydraulics
| Total Pump Flow | 6.97 gpm (26.4 L/min) |
3-Point Hitch
| Standard Category | Category 1 |
| Maximum Lifting Capacity (24”aft. of hitch) | 700 lbs. (318 kg) |
| Control Type | Position |
Weight
| Weight w/ Ag Tires w/ ROPS | 1,554 lbs. (705 kg) |
